CADRA Design Drafting软件特征：

Drafting Engine

• ƒ 2-1/2D view-based drafting
• Full 3D wireframe support
• 3D bidirectional integration

Productivity

• ƒQuickDim for intelligent dimensioning
• QuickPick for rapid selection and insertion of parts, layers, and overlays
• QuickHatch for crosshatching
• QuickTrim for trimming and cornering
• FlexDesign adds dimension-driven variational and design capabilities
• Planar, step, and complex sectioning with cross-hatch control
• Preview of geometry to be created
• In-place figure editing
• In-drawing multiple language text
• Plot preview
• Plots PDFs
• Bidirectional HPGL format
• Microsoft Office integration through OLE
• Preview the drawing in open dialog

Design Automation

• Macro programming language
• Visual Basic Object model interface
• CADRALIB commonly used parts
• CADRABOM bill of materials automation
• CADRAEDM data management facility

ƒRead and/or write to CADAM CADDS, DWG, DXF, IGES, PDF, HPGL, MICROCADAM, CATIA, CCD, and Gerber
